Axiom SW18A
NUOVO! Subwoofer attivo con processore CORE – Woofer 18"
Codice prodotto: SW18A
€0,00
Acquisto su prenotazione. Inviaci una mail per conoscere i tempi di consegna!
CONTATTACI PER RICEVERE UN PREVENTIVO PERSONALIZZATO!!
Subwoofer attivo con processore CORE - Woofer 18"
CARATTERISTICHE
| SYSTEM | |
| System’s Acoustic Principle | Direct radiation, vented |
| Frequency Response (-6dB) | 36 Hz - 100 Hz (Processed) |
| Maximum (peak) Output | 132 dB SPL @ 1m |
| TRANSDUCERS | |
| Type | 18", 4" VC |
| Cone | High stiffness, water repellent, glass fiber reinforced diaphragm |
| Voice Coil Type | Flux Demodulating Ring |
| Suspension | Double Centering Spider |
| ELECTRICAL | |
| Input Impedance | 20 kΩ balanced, 10 kΩ unbalanced |
| Input Sensitivity | +4dBu / 1.25 V |
| Signal Processing | CORE processing, 96kHz / 40bit floating point SHARC DSP, 24 bit AD/DA converters |
| Direct access Controls | 4 Presets (STANDARD/INFRASUB/CARDIOID/USER), Network Termination, GND Link |
| Remote Controls | PRONET control software |
| Network protocol | CANBUS |
| Amplifier Type | Class D with SMPS, Variable Switching Frequency |
| Output Power | 2000W |
| Mains Voltage Range (Vac) | 230V ±15% - 115 ±15% 50/60Hz (internally selectable) |
| IN / OUT Connectors | Neutrik XLR-M / XLR-F |
| IN / OUT Network Connectors | ETHERCON®(NE8FAV) |
| Mains Input Connector | PowerCon® (NAC3MPA) |
| Mains Link Connector | PowerCon® (NAC3MPB) |
| Cooling | Variable speed DC fan |
| ENCLOSURE & CONSTRUCTION | |
| Width | 650 mm |
| Height | 500 mm |
| Depth | 564 mm |
| Depth Including Wheels | 673 mm |
| Enclosure Material | 15mm, reinforced phenolic birch |
| Paint | High resistance, water based paint |
| Wheels | 4 x 100mm Polyurethane Wheels |
| Net Weight | 42.5 kg (93.7 lbs) |
